1-1/2” Snap-Lok Clip Roof Panel
145SLAllSeam
1-1/2" Snap-Lok Clip
The 145SLAllSeam is designed for efficiency, precision, and lasting performance, making it a smart choice for both residential and commercial roofing applications. Its 1-1/2" seam height and narrow 5/32" seam width create refined, clean lines with a crisp architectural look. The traditional clip system provides a secure, concealed connection without exposed fasteners while allowing for natural thermal movement. Engineered for strength and style, the 145 Snap-Lock system combines straightforward installation with a modern, streamlined appearance.
Panel Specifications
-
Seam: Snap-Lok Clip ─ No Mechanical Seaming
-
Rib Height: 1-1/2”
-
Rib Width: 5/32"
-
Panel Coverage: 15-1/2”
-
Material:
-
Steel - 22ga, 24ga, 26ga
-
Aluminum - .032, .040
-
Zinc – 7mm
-
-
Minimum Slope: 2:12
-
Support: Plywood, Wood Plank
-
Product Approvals: Florida Product, HVHZ, TDI
-
UL Listed
-
Options: (contact panel manufacturer for availability)
-
Clip Relief
-
Striations
-
Weathertight Warranty Eligible
-
